T20-71 Timing Pulley

Description

T20-71 Timing Pulley is a specific type of timing pulley used in power transmission systems. Here's some information about this particular pulley:

Size: The designation "T20-71" indicates the tooth profile and belt length. In this case, it refers to a T (Tooth) tooth profile and a belt length of 71 teeth.
Material: The material used for this timing pulley can vary but is typically made from aluminum, steel, or other durable materials depending on the application requirements.
Belt Profile Compatibility: The T20 designation corresponds to a specific tooth profile, which must match with the corresponding timing belt that also has a T20 profile for proper operation and synchronization in the power transmission system.
Application: Timing pulleys are commonly used in various industrial applications where precise motion control and synchronization are required, such as conveyors, robotics, printing machinery, and CNC machines.

Product details

TIMING PULLEYS T20-71

T20-71

SPC TYPE Z De Df Dm F L d 71-T20-18 2F 18 111.75 120 80 56 71 18 71-T20-20 2F 20 124.5 142 90 56 71 18 71-T20-22 2F 22 137.2 150 90 56 71 18 71-T20-24 2F 24 149.95 158 95 56 71 18 71-T20-25 2F 25 156.3 168 95 56 71 18 71-T20-30 2F 30 188.15 200 110 56 71 18 71-T20-32 4 32 200.85 216 110 56 71 20 71-T20-36 4 36 226.35 - 110 56 71 20 71-T20-40 5 40 251.8 - 110 56 71 20 71-T20-48 5 48 302.7 - 130 56 71 24 71-T20-60 5 60 379.1 - 130 56 71 24 71-T20-72 5 72 455.5 - 140 56 71 24
