Chain manufacturers explain short pitch precision roller chains

Short pitch precision roller chain(B series) is the basic Transmission Chain, some specifications are configured. It can be used as Conveyor Chain after attachment.

I. Name

1) Standard name: Short pitch precision roller conveyor chain

2) Other names: standard roller conveyor chain, short pitch conveyor chain

3) English name: Short pitch precisi6n rol1er chain for conveyors

2, structural components

(1) Structure diagram Figure 2-l3 is an external view of a short-pitch precision roller conveyor chain, and Figure 2-l4 is a structural diagram of a short-pitch precision roller conveyor chain.

Components of Short Pitch Precision Roller Chain(A Series) structure

(2) Structural characteristics and components The short-pitch precision roller conveyor chain is composed of the short-pitch precision roller drive chain with corresponding accessories. The basic chain is the standard roller drive chain. The main components include accessories in addition to the inner and outer chain plates, pins, sleeves, rollers.

III. Features and Applications

The short-pitch precision roller conveyor chain is characterized by precise manufacturing. The chain pitch is small, and the pitch range is between 12.7mm and 50.8mm. The pitch specifications of other conveyor chains are usually larger. Therefore, it is suitable for conveying objects that are not too bulky and small in size.
