2060/2062 Double Pitch Sprocket
  1. 2060/2062 Double Pitch Sprocket

2060/2062 Double Pitch Sprocket

Product Item:HXST-106

Model:2060/2062 Double Pitch Sprocket

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

2060/2062 Double Pitch Sprocket , 2060 chain sprocket , c2060h sprocket , c2060 roller chain
Send InquiryLive chat

Description

2060/2062 Double Pitch Sprocket is a type of sprocket designed for use with Double Pitch Roller Chains, specifically the 2060 and 2062 series chains. These sprockets are commonly used in applications where slower speeds and lighter loads are involved, such as conveyor systems, material handling equipment, and agricultural machinery.

Here are some key features and characteristics of the 2060/2062 Double Pitch Sprocket:

Double Pitch Design: The sprocket is specifically engineered to accommodate double pitch roller chains, which have longer pitch lengths compared to standard roller chains. This design allows for greater spacing between the chain links, resulting in reduced weight and lower cost.

Compatibility: The 2060/2062 Double Pitch Sprocket is compatible with 2060 and 2062 series chains. These chains are commonly utilized in applications where lighter loads and slower speeds are prevalent.

Tooth Configuration: The sprocket is equipped with teeth that are designed to engage with the corresponding links of the double pitch chain. The tooth profile and dimensions are carefully crafted to ensure efficient power transmission while minimizing wear and noise.

Material and Construction: The sprocket is typically constructed from durable materials such as steel or alloy, ensuring strength and longevity. It may undergo various treatments or coatings to enhance corrosion resistance and overall performance.

Variations: The 2060/2062 Double Pitch Sprocket is available in different configurations, including various numbers of teeth, bore sizes, and hub designs. This allows for customization and adaptation to specific application requirements.
