What is the difference between 06B and 06C, European standard chain and American standard chain

What is the difference between 06B and 06C

The 06B chain is a short-pitch precision roller chain, and the chain plate is a straight chain.

06B straight chain

The 06C chain is a sleeve chain. The chain plate is "∞ word chain plate".

06C chain

In the data, the pitch of 06B chain and 06C chain is the same, both are 9.525mm, and 06C has no rollers. The roller diameter is replaced by the sleeve diameter.

Comparison: Pitch Roller diameter (sleeve) Inner section inner width Pin shaft diameter Pin shaft length Inner chain plate height Chain plate thickness Tensile load weight per meter

06B 9.525mm 6.35mm 5.72mm 3.28mm 14.1mm 8.2mm 1.3mm 10.4KN 0.41KG

06C 9.525mm 5.08mm 4.77mm 3.58mm 13.17mm 9mm 1.3mm 10.8KN 0.33kg
