T20-123 Timing Pulley

Description

T20-123 Timing Pulley is a specific type of timing pulley used in power transmission systems. Here's some information about this particular pulley:

Size: The designation "T20-123" indicates the tooth profile and belt length. In this case, it refers to a T (Tooth) tooth profile and a belt length of 123 teeth.
Material: The material used for this timing pulley can vary but is typically made from aluminum, steel, or other durable materials depending on the application requirements.
Belt Profile Compatibility: The T20 designation corresponds to a specific tooth profile, which must match with the corresponding timing belt that also has a T20 profile for proper operation and synchronization in the power transmission system.
Application: Timing pulleys are commonly used in various industrial applications where precise motion control and synchronization are required, such as conveyors, robotics, printing machinery, and CNC machines.

Product details

TIMING PULLEYS T20-123

T20-123

SPC TYPE Z De Df Dm F L d 123-T20-18 2F 18 111.75 120 80 108 123 24 123-T20-20 2F 20 124.5 142 90 108 123 24 123-T20-22 2F 22 137.2 150 90 108 123 24 123-T20-24 2F 24 149.95 158 95 108 123 24 123-T20-25 2F 25 156.3 168 95 108 123 24 123-T20-30 2F 30 188.15 200 110 108 123 24 123-T20-32 4 32 200.85 216 110 108 123 24 123-T20-36 4 36 226.35 - 110 108 123 32 123-T20-40 5 40 251.8 - 110 108 123 32 123-T20-48 5 48 302.7 - 130 108 123 32 123-T20-60 5 60 379.1 - 130 108 123 32 123-T20-72 5 72 455.5 - 140 108 123 32
