T10-40 Timing Pulley
  1. T10-40 Timing Pulley
  2. T10-40 Timing Pulley

T10-40 Timing Pulley

Product Item:HXST-241

Model:T10-40 Timing Pulley

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

t10 timing pulleys , t10 timing belt pulley , t10 pulley
Send InquiryLive chat

Description


Timing PulleyS T10-40


T10-40

SPC TYPE Z De Df Dm F L d
40-T10-12 2F 12 36.35 43 28 30 40 6
40-T10-14 2F 14 42.7 48 32 30 40 8
40-T10-15 2F 15 45.9 51 32 30 40 8
40-T10-16 2F 16 49.1 54 35 30 40 8
40-T10-18 2F 18 55.45 60 40 30 40 8
40-T10-19 2F 19 58.65 67 44 30 40 8
40-T10-20 2F 20 61.8 67 46 30 40 8
40-T10-22 2F 22 68.2 75 52 30 40 8
40-T10-24 2F 24 74.55 83 58 30 40 8
40-T10-25 2F 25 77.75 83 60 30 40 8
40-T10-26 2F 26 80.9 87 60 30 40 8
40-T10-27 2F 27 84.1 91 60 30 40 8
40-T10-28 2F 28 87.25 94 60 30 40 8
40-T10-30 2F 30 93.65 97 60 30 40 8
40-T10-32 2F 32 100 112 65 30 40 10
40-T10-36 2F 36 112.75 120 70 30 40 10
40-T10-40 2F 40 125.45 135 80 30 40 10
40-T10-44 2 44 138.2 - 88 30 40 10
40-T10-48 2 48 150.95 - 95 30 40 16
40-T10-60 2 60 189.15 - 110 30 40 16
