H075 Timing Pulley

Product Item:HXST-224

Model:H075 Timing Pulley

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

Description

H075 Timing Pulley is a type of pulley used in timing belt systems. It is designed to work with a specific pitch of timing belt, typically the 3/8" (0.375") pitch. The "H075" designation refers to the pulley's size and specifications.

Here are some key features of the H075 timing pulley:

Size: The "H075" designation indicates that the timing pulley has a pitch diameter of 0.75 inches. This means that it is compatible with timing belts designed for this specific size.

Material: Timing pulleys are commonly made from materials such as aluminum or steel. The exact material used for the H075 timing pulley may vary depending on the manufacturer and application.

Teeth: The H075 timing pulley will have a certain number of teeth that correspond to the pitch of the timing belt it is designed to work with. The teeth are precisely spaced to engage with the corresponding teeth on the timing belt, ensuring accurate synchronization of rotational movements.

Mounting: The H075 timing pulley may have different mounting options depending on the specific application. Common mounting methods include set screws, keyways, or clamping mechanisms.

Applications: Timing pulleys, including the H075 size, are commonly used in various applications where precise timing and motion control are required. They are often found in machinery and equipment such as printers, robotics, CNC machines, and conveyor systems.
