ANSI 40A-2 47T Double Plate wheel chain sprocket

Product Item:HXPT-063

Model: ANSI 40A-B-1-2-3 Sprockets and Platewheel

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

ANSI 40-2 Plate Steel Sprocket

For #40 Double Strand Chain with

1/2 Inch Pitch

5/16 Inch Roller Width

0.313 Inch Roller Diameter

0.283 Inch Single Tooth Width (B1)

0.843 Inch Sprocket Tooth Face Width (B2)

7.748 Inch Outside Diameter (Approximate) (de)

Without Hub (Plate Type)

13/16 Inch Inch approximate Pilot hole / bore +/- 1/16 inch (d1)

0.843 Inch Inch Total Width (A)
