60B-3 Sprockets With Split Taper Bushing

Product Item:HXST-111

Model:60B-3 Sprockets With Split Taper Bushing

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

Description

The "60B-3 sprockets" refer to a specific type of sprocket with the designation "60B-3". The "60B-3" indicates that it is a sprocket designed for a 3/4 inch pitch roller chain, and the "-3" signifies that it has three strands or rows of teeth.

The "split Taper Bushing" is a type of bushing used for mounting sprockets onto shafts. It features a split design, allowing for easy installation and removal without the need to disassemble other components. The split taper bushing provides a secure and tight fit between the sprocket and the shaft, ensuring efficient power transmission.
