4 Plate Universal Joint

Product Item:HXST-1805

Model: 4 Plate Universal Joint

Material: It is typically made from durable materials such as steel or alloy steel to withstand high torque and provide long-lasting performance.

Misalignment Capability: It is designed to accommodate angular misalignment between the input and output shafts, allowing for flexibility in shaft alignment

Application: 4-plate universal joints are commonly used in various applications, including automotive drivelines, industrial machinery, agricultural equipment, and more

Description

A 4-plate universal joint is a specific type of mechanical joint used to transmit rotational motion between two shafts that are not aligned with each other. Here's an explanation of its components:

Plates: The plates, also called flanges or discs, are the main components of the universal joint. They typically have a circular shape and are connected by a center block or cross-shaped element.
The 4-plate universal joint operates by connecting two shafts at an angle to each other while allowing for angular misalignment and axial movement. The plates are arranged in pairs and connected by the center block, enabling smooth rotational movement between the shafts.

This type of universal joint is commonly used in various applications where flexibility, reliability, and efficient power transmission are required, such as automotive drivetrains, industrial machinery, and power transmission systems.

Proper lubrication and maintenance are essential to ensure the longevity and optimal performance of the 4-plate universal joint. Additionally, it's important to consider the load capacity and operating conditions when selecting a suitable size and material for the universal joint to meet the specific requirements of the application
