100B-1 Sprockets With Split Taper Bushing
  1. 100B-1 Sprockets With Split Taper Bushing

100B-1 Sprockets With Split Taper Bushing

Product Item:HXST-113

Model:100B-1 Sprockets With Split Taper Bushing

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

100B-1 Sprockets With Split Taper Bushing , sprocket with bushing , split taper sprocket
Send InquiryLive chat

Description

The 100B-1 Sprockets With Split Taper Bushing is a type of sprocket used in power transmission systems. It is designed to accommodate a split taper bushing, which allows for easy installation and removal from the shaft.

Here are some key features and specifications of the 100B-1 Sprockets With Split Taper Bushing:

Type: 100B-1
Number of teeth: 100
Pitch diameter: varies depending on the specific configuration
Material: Typically made from high-quality steel or other durable materials for maximum strength and longevity.
Tooth profile: Designed to engage with a corresponding chain, providing smooth and efficient power transmission.
Split taper bushing: Allows for quick and convenient mounting and dismounting from the shaft without the need for specialized tools. The split taper design provides a tight and secure fit on the shaft, minimizing slippage and ensuring reliable performance.
Application: These sprockets are commonly used in various industrial applications, such as conveyor systems, power transmission equipment, and machinery that requires precise and reliable motion control.
